Description
Quiet EC Extraction That Keeps Heat and Odour in Check
The AC Infinity Cloudline LITE A-Series Inline Fan is a quiet EC-motor inline duct fan for pulling hot, stale or smelly air out of a grow tent or room and through your ducting and carbon filter. It ships with a 10-speed manual controller for dialling in the airflow you need, and it is UIS-upgradeable if you want to bring it into an automated setup later. The LITE keeps the efficient EC motor of the PRO range at a more accessible price for straightforward manual extraction.
Key Benefits
- Quiet EC motor for efficient extraction without excessive noise
- 10-speed manual controller included for precise airflow adjustment
- UIS-upgradeable for automated speed control via a UIS controller later
- Three sizes: 100mm (~165 CFM / 280 m3/h), 150mm (~352 CFM / 598 m3/h) and 200mm (~724 CFM / 1,230 m3/h)
- Effective odour control, moving air efficiently through ducting and carbon filters
Tent Running Warm or Holding Onto Smell?
A tent that runs too warm under the lights, or holds onto smells because extraction is too weak for the space, is one of the most common grower problems. The Cloudline LITE pulls hot, humid, odorous air out through your carbon filter, keeping fresh air moving and reducing the risk of heat stress, mould and smell escaping. Across 10 speeds you can match extraction to the season, lower in winter, higher in a summer heatwave or heavy flower.
How to Use
- Mount the fan in your extraction ducting, pulling air from the top of the tent through a carbon filter
- Connect the manual controller and set speed by tent temperature and smell
- Increase it if the tent runs warm, decrease it if airflow is stronger than needed
- For automated control, connect it to a compatible UIS controller instead
Technical Specifications
- Motor: EC, dual ball bearings
- Airflow by size: 100mm ~165 CFM / 280 m3/h, 150mm ~352 CFM / 598 m3/h, 200mm ~724 CFM / 1,230 m3/h
- Control: included 10-speed manual controller, UIS-upgradeable
- Voltage: 100-240V AC, 50/60Hz
- Noise: low-noise EC operation, reducing at lower speeds
- Use: inline duct extraction through ducting and carbon filter
- Noise, A4: 29 dB(A)
- Noise, A6: 34 dB(A)
- Noise, A8: 42 dB(A)
- Power, A4: 35 W max
- Power, A6: 65 W max
- Power, A8: 190 W max
- Static pressure, A4: 324 Pa
- Static pressure, A6: 394 Pa
- Static pressure, A8: 746 Pa
- Airflow, A4: 280 m³/h
- Airflow, A6: 598 m³/h
- Airflow, A8: 1,230 m³/h
